Semi automatic Cleaner aerosol filling machine
1. Liquid filler
Double-Head Liquid Filler adopts the advanced technologies for Italy Costas fillers, and thus features safe and easy operation, quick filling speed, large filling capacity, fine liquid quality and high compactness etc. It’s of broad application for the filling of daily chemicals, fire fighting products and agricultural chemicals such as perfumes, hair oils, pesticides, lubricants, antiseptics and LPG etc.
|
Max. Capacity (ml) |
500 |
|
|
Repeat Filling Accuracy |
±1.0% |
|
|
Aerosol Can Applied |
Height (mm) |
60-350 |
|
Dia. (mm). |
20-100 |
|
|
Working Pressure (MPa) |
0.45-0.7 |
|
|
Max. Air Consumption (l/min) |
180 |
|
|
Production Capacity (Can/hr.) |
800-1200 |
|
|
Sizes (mm) |
500×400×770 |
|
|
Mass (Kg) |
85 |
|
2. Aerosol Crimper
is applic able for the outer clawing type capping of international universal 1 inch air valve caps. It is characterized by security, easy operation, high capping speed, excellent capping quality and tightness etc.
|
Capping Dia. (mm) |
(26.5-28.5)±0.15 |
|
|
Capping Depth |
(0-7)±0.15 |
|
|
Min. Vacuum |
1×10-3 |
|
|
Air Valve Cap Applied |
1 inch (25.4mm) |
|
|
Aerosol Can Applied |
Height |
60-350mm |
|
Diameter. |
20-100mm |
|
|
Working Pressure (MPa) |
0.45-0.7 |
|
|
Max. Air Consumption l/min |
12 |
|
|
Production Capacity Can/hr. |
1000-1500 |
|
|
Sizes (mm) |
500×400×700mm |
|
|
Mass (Kg) |
72 |
|
3. Aerosol Propellant Filler
Aerosol Propellant Filler (Air Inflator) is widely used for the quantitative filling of various aerosol propellants e.g. propane, butane, Freon, Co2, nitrogen, oxygen, compressed air, LPG, F12, DME etc. The machine features safe operation, accurate quantifying, precise repetition and broad applications etc.
|
Repeat Filling Accuracy |
≤±1.0% |
|
|
Max. Filling Capacity |
500ml |
|
|
Lowest Vacuum Degree (bar) |
1×10-3 |
|
|
Aerosol Can Applied |
Height |
60-350mm |
|
Dia. |
20-100mm |
|
|
Operation Pressure |
0.45-0.7MPa |
|
|
Max. Air Consumption |
0.4m3/min |
|
|
Production Capacity |
800-1200 Can/hr. |
|
|
Sizes |
900×550×1800mm |
|
|
Weight |
110kg |
|
