Semi automatic air freshener aerosol filling machine

Semi automatic air freshener aerosol filling machine

Features

• This machine is applied to filling such mediums as compress air, hydrocarbon mixture .Freon ,DME, Nitrogen,and Carbon Dioxide and so on . It can produce various aerosol products;
• Filling system newly applied for air compressor equipment, are suitable for dosing filling any kinds of viscosity. No need to configurate a paste filling machine, can save lots of money;
• It can continuously complete gas blowing, feeding, filling, sealing automatically. With the original technical design, it is easy to operate saving time and effort;
• German PTFE seals, wearing-resistant, long lifetime up to more than 5 years;
• Its filling end is controlled separately, no discharging without filling;It is sealing with high quality for adopting oriented-sealing; The way of the oriented inflation in the charging end is accurate and efficient with minimal gas consumption;
• This machine is in advanced level of the same industry at present. It have been exported to Europe, America, Africa, southeast Asia. It's the best choice to set aerosol factory;

Technical parameters

Filling volume(ml): 20-750ml(specification can be made by request);
Filling accuracy: ≤±1%
Gas volume(ml): 20-450ml
Gas accuracy: ≤±1%
Sealing accuracy: ≤±1%
Working Pressure: 0.65-1.0MPa
Available valve: 1”(25.4mm)
Production capacity: 4000-5000cans/day
Maximum air consumption: 0.8(m3/min)
Applicable aerosol can diameter: 35-65 (mm)
Applicable aerosol can height: 80-350(mm)
Packing dimension and weight:
Filling machine : 1000*590*1590mm 180KG
Booster pump : 500* 450*600mm 38KG
