Air freshener Automatic Aerosol Filling Machine in Thailand
Air freshener Automatic Aerosol Filling Machine in Thailand
Description:
AF-50 Automatic Aerosol Filling Machine is mainly used to fill all kinds of aerosol cans with international standard 1" valve. It can be suitable for filling water, oil, etc medium-viscosity liquid, Also suitable for filling many kinds of propellant. The line can be equipped with Automatic Ball Dropper, Automatic Valve Placer, Automatic Weight Checker, Automatic Actuator Placer, automatic cap presser, automatic spray code machine, automatic water bath leakage tester,etc.
Specifications:
Model
AF-50A
Filling capacity
15-750ml (can be customized)
Filling accuracy
≤±1%
Propellant filling capacity
15-750ml (can be customized)
Propellant filling accuracy
≤±1%
Capping accuracy
≤1%
Production capacity
2400-3600 cans/hr
Air source
0.6Mpa-1Mpa clean and stable air source
Max air consumption
3 M³/min
Can Height
80~330
Can Diameter
Φ35~Φ80
Weight
about 2000kg
Dimension(L×W×H)
12000×1500×2100
